jcb 455ZX - Main Component Locations

01 - Machine
09 - Description
12 - Main Component Locations
01 - 21 9813/4800-3 01 - 21
12 - Main Component Locations
Introduction
Figure 5.
A
B
C
Q
K
J
L
H
C
F
D
P
E
M
N
G
A Shovel B Loader arms
C ROPS (Roll-Over Protective Structure)/FOPS
(Falling Object Protective Structure) cab
D Hydraulic fluid fill point
