jcb 4CX - Speed Sensor Test Harness -Powershift Gearbox; Thrust Washer Kit - Powershiftgearbox - Layshaft Clutch

1 - 8
Section F
Transmission
9803/3280
Section F
1 - 8
Issue 3*
Service Tools
Service Tools (cont'd)
892/01094 Transmission Jack
When removing the Powershift gearbox use of a special
transmission jack is strongly recommended. This jack
can also be used when removing Synchro Shuttle
gearboxes.
Note that the jack must be used with special support
plates, see the facing page for details.
892/01083 Powershift - Assembly tool,
transfer gear
892/01084 Powershift - Transfer gear, bearing
assembly
892/01085 Powershift - Seal fitting tool
A402680
823/10420 Thrust Washer Kit - Powershift
gearbox - Layshaft clutch
Comprises of:
Washer thickness mm
823/10421 4.3
823/10422 4.4
823/10423 4.5
823/10424 4.6
823/10425 4.7
823/10426 4.8
*
*
892/01096 Speed Sensor Test Harness -
Powershift Gearbox
*
