85 - 1
Removal and Replacement
(2 Wheel Drive Machines)
The removal and replacement procedures for the 2 wheel
drive axle (beam type) is the same as described on pages
F/80-1 and F/80-2. Dis-regard any information which is not
pertinent to the 2 wheel drive axle.
Please note when using a 'cradle' to remove the axle from
the machine, the balance point (see step 10, page F/80-2),
of the axle on 2 wheel drive machines will be the centre of
the axle, NOT offset as described on page F/80-2.
Section F Transmission
9803/3280
Section F
85 - 1
Issue 1
Front Axle
