Introduction
About This Manual
Machine Model and Serial Number
This manual provides information for the following
model(s) in the JCB machine range:
3CX / 4CX from 1349424 to 1349999
3CX / 4CX from 1616000 to 1625999
Using this Manual
INT-1-2-5_4
This manual is arranged to give you a good understanding
of the machine and its safe operation. It also contains
maintenance information and specification data. Read this
manual from front to back before using the machine for the
first time. Particular attention must be given to all the safety
aspects of operating and maintaining the machine.
Do not operate the machine without an Operator Manual.
Treat the Operator Manual as part of the machine. Keep it
clean and in good condition. Replace the Operator Manual
immediately if it is lost, damaged or becomes unreadable.
If there is anything you are not sure about, ask your JCB
distributor or employer. Do not guess, you or others could
be killed or seriously injured.
General warnings in this chapter are repeated throughout
the book, as well as specific warnings. Read all the safety
statements regularly, so you do not forget them.
Remember that the best operators are the safest
operators.
The illustrations in this manual are for guidance only.
Where the machines differ, the text and or the illustration
will specify.
The manufacturer's policy is one of continuous
improvement. The right to change the specification of the
machine without notice is reserved. No responsibility will
be accepted for discrepancies which may occur between
specifications of the machine and the descriptions
contained in this publication.
All optional equipment included in this manual may not be
available in all territories.
Units of Measurement
T1-001_2
In this publication, the S.I. system of units is used. For
example, liquid capacities are given in litres. The Imperial
units follow in parentheses ( ) eg 28 litres (6 gal).
Left Side, Right Side
P2-1002
In this manual, 'left' A and 'right' B mean your left and right
when you are seated correctly in the machine.
This is so whether you are facing the loader (front) or the
backhoe (rear).
C003690
Fig 1.
Using the Machine
T1-002_2
To use the machine efficiently and safely you must know
the machine and have the skill to use it. You must abide by
all relevant laws, health and safety regulations that apply
to the country you are operating in. This manual instructs
you on the machine, its controls and its safe operation; it is
not a training manual. If you are a new operator, get
yourself trained in the skills of using a machine before
trying to work with it. If you don't, you will not do your job
well, and you will be a danger to yourself and others.
A
B
A
B
