01 - Machine
09 - Description
15 - Service Point Locations
01 - 23 9813/6400-2 01 - 23
Engine Compartment
Figure 5.
C
D
A
B
A Coolant expansion bottle B Washer bottle
C Engine fuel filter D Engine oil dipstick
