15 - Engine
00 - General
00 - General
15 - 11 9806/6900-3 15 - 11
Figure 8. Crankshaft pulley (front) end
A Rocker cover B Cylinder head
C Crankcase D Bedplate
E Lubrication oil sump F Torsional vibration damper
G FEAD (Front End Accessory Drive) tensioner H Starter motor
J Alternator and drive pulley assembly K Twin thermostat
L Turbocharger
