15 - Service Point Locations
Introduction
Service Points - Hydraulics
Figure 4. Upper structure
A Breather - hydraulic tank B Cover - suction strainer
C Cover - return filter D Excavator control valve block
E Filter - rockbreaker return line F Filter -in-line (cushion valve)
G Oil level dipstick - slew motor gearbox H Oil filler tube - slew motor gearbox
J Oil drain plug - slew motor gearbox (access
from below the machine)
