01 - Machine
09 - Description
15 - Service Point Locations
01 - 24 9813/8700-1 01 - 24
Service Points - Engine
Figure 6. Upper structure
A Exhaust system B Crankcase ventilation filter
C Engine oil filler port D FEAD (Front End Accessory Drive) belt
E Fan Belt F Coolant expansion bottle
G Engine oil level dip stick H Engine oil drain point (access from below the
machine)
J Pre-cleaner (if installed)
