jcb JCB380 - Page 31

01 - Machine
09 - Description
15 - Service Point Locations
01 - 25 9813/8700-1 01 - 25
Figure 7. Battery / cooling compartment
D
E
H
B
A
C
G F
A Safety air filter element B Primary air filter element
C Scavenge intake D Battery compartment
E Cooling pack compartment F Fuel cooler matrix
G Drain plug, coolant (access under machine) H Cooling pack
