jcb JS 200 Series - Hydraulic Connections; O Ring Face Seal System

Section 1-7 - General Information
Torque Settings
Hydraulic Connections
1-7-8 1-7-8
1-05-01 Issue 02
Adaptors into Component Connections with Bonded Washers
Table 11. BSP Adaptors with Bonded Washers - Torque Settings
BSP Size
Nm kgf m lbf ftin.
1/8 20.0 2.1 15.0
1/4 34.0 3.4 25.0
3/8 75.0 7.6 55.0
1/2 102.0 10.3 75.0
5/8 122.0 12.4 90.0
3/4 183.0 18.7 135.0
1 203.0 20.7 150.0
1 1/4 305.0 31.0 225.0
1 1/2 305.0 31.0 225.0
