jcb JS145W

01 - Machine
09 - Description
12 - Main Component Locations
01 - 17 9813/2650-3 01 - 17
12 - Main Component Locations
Component Identification
Figure 4.
A
H
F
G
B
C
E
D
K
J
L
A Bucket B Bucket link
C Bucket ram D Dipper
E Dipper link F Dipper ram
G Boom H Boom ram
J Operators cab K Counterweight
L Undercarriage
