12
VARIABLE SPEED SELECTOR
The variable speed selector dial is used to control the speed at
which the saw operates. This is known as the blade stroke rate. To
pre-select the required blade stroke rate, turn the selector
dial to the relevant number. A low number gives a low stroke rate
and a high number gives a high stroke rate. The stroke rate should
be adjusted according to the material being cut. The table below
shows some recommended settings. It should only be used as a
guide. Make a test cut on a scrap of material to ensure that the
correct stroke rate has been selected.
Material Setting
Wood 5 - 6
Metal 2 - 3
Aluminium 3 - 5
PVC 3 - 4
OPERATING THE TRIGGER SWITCH
To switch the jigsaw on, fully squeeze the ON/OFF trigger switch.
To switch the jigsaw off, release the trigger switch. If continuous
operation is required, the trigger switch can be locked in the ON
position. To lock the switch ON, squeeze the trigger switch, press
the lock-on button and release the trigger switch. To release the
lock-on button squeeze the trigger switch and then release it.
Make sure that you release the lock-on button before
disconnecting from the mains supply. Before plugging the jigsaw
into the mains supply, make sure that the trigger switch is in the
OFF position.
Switch in Off position Switch in locked-On position
Variable speed
selector dial
