Section 1 - General Information
1 - 9
9803-6530
1 - 9
Service Tools
Numerical List Section B - Body and Framework
The tools listed in the table are special tools required for
removal and replacement of Body and Framework parts.
These tools are available from JCB Service.
Tools other than those listed will be required. It is
expected that such general tools will be available in any
well equipped workshop or be available locally from any
good tool supplier.
Part
Number
Description Tool D e t a il
Reference
4104/1310 Hand Cleaner Fig 1. (
X 1-10)
826/01099 M6 x 16mm Rivet Nut Fig 2. (X 1-10)
826/01101 M6 x 19mm Rivet Nut Fig 2. (X 1-10)
826/01102 M8 x 21mm Rivet Nut Fig 2. (X 1-10)
826/01103 M8 x 18mm Rivet Nut Fig 2. (X 1-10)
826/01104 M10 x 23mm Rivet Nut Fig 2. (X 1-10)
826/01105 M10 x 26mm Rivet Nut Fig 2. (X 1-10)
892/00842 Glass Lifter Fig 3. (X 1-10)
892/00843 Folding Stand for Holding Glass Fig 4. (X 1-10)
892/00844 Long Knife Fig 5. (X 1-11)
892/00845 Cartride Gun Fig 6. (X 1-11)
892/00846 Glass Extractor (Handles) Fig 7. (X 1-11)
892/00847 Nylon Spatula Fig 8. (X 1-11)
892/00848 Wire Starter Fig 9. (X 1-11)
892/00849 Braided Cutting Wire Fig 10. (X 1-11)
926/15500 Rubber Spacer Blocks Fig 11. (X 1-12)
992/12300 12V Oven Fig 12. (X 1-12)
992/12400 240V Oven 2 Cartridge Fig 13. (X 1-12)
992/12600 240V Oven 6 Cartridge Fig 13. (X 1-12)
992/12800 Cut-Out Knife Fig 14. (X 1-12)
992/12801 ‘L’ Blades Fig 15. (X 1-12)
