Dacromet Fasteners (mottled silver finish)
9803-6530
Dacromet Fasteners (mottled silver finish)
Use only where no torque setting is specified in the text.
plating process: do not lubricate.
Metric Grade 8.8 Bolts
Metric Grade 10.9 Bolts
Metric Grade 12.9 Bolts
Bolt Size Torque Settings
Dia Nm kgf m lbf ft
M6 x 1.0 9 0.9 7
M8 x 1.25 22.5 2.3 17
M10 x 1.5 47.5 4.8 35
M12 x 1.75 80 8.2 59
M14 x 2 133 13.6 98
M16 x 2 200 20.4 148
M18 x 2.5 278 28.4 205
M20 x 2.5 392 40 289
M24 x 3 675 69 498
M30 x 3.5 1348 138 994
Bolt Size Torque Settings
Dia Nm kgf m lbf ft
M6 x 1.0 13.5 1.4 10
M8 x 1.25 35 3.6 26
M10 x 1.5 62.5 6.4 46
M12 x 1.75 115 11.7 85
M14 x 2 175 17.9 129
M16 x 2 300 30.6 221
M18 x 2.5 395 40 291
M20 x 2.5 559 57 412
M24 x 3 962 98 710
M30 x 3.5 1920 196 1416
Bolt Size Torque Settings
Dia Nm kgf m lbf ft
M6 x 1.0 15 1.5 11
M8 x 1.25 40 4.1 29
M10 x 1.5 80 8.2 59
M12 x 1.75 133 13.6 98
M14 x 2 225 23 166
M16 x 2 350 35.7 258
M18 x 2.5 463 47 342
M20 x 2.5 654 67 482
M24 x 3 1125 115 830
M30 x 3.5 2247 229 1657
