Section 1 - General Information
Service Tools
Tool Detail Reference Section B - Body and Framework
1 - 11
9803-6530
1 - 11
Fig 5. 892/00844
Note: - used to give extended reach for normally
inaccessible areas.
Fig 6. 892/00845
Note: - hand operated - essential for the application of
sealants, polyurethane materials etc.
Fig 7. 892/00846
Note: - used with braided cutting wire (below) to cut
out broken glass.
Fig 8. 892/0847
Note: - general tool used for smoothing sealants - also
used to re-install glass in rubber glazing because metal
tools will chip the glass edge.
Fig 9. 892/00848
Note: - used to access braided cutting wire through
original polyurethane seal.
Fig 10. 892/00849
Note: - (approx 25 m length) consumable heavy duty
cut-out wire used with the glass extraction tool.
