jcb JZ140 ZT

Section 1 - General Information
Service Tools
Numerical List Section E- Hydraulics
1 - 17
9803-6530
1 - 17
892/00263 Pressure Test ‘T’ Adapter 5/8 in BSP x 5/8 in F BSP x Test Point Fig 24. (X 1-19)
892/00264 Pressure Test ‘T’ Adapter 3/4 in BSP x 3/4 in F BSP x Test Point Fig 24. (X 1-19)
892/00265 Pressure Test ‘T’ Adapter 1 in M BSP x 1 in F BSP x Test Point Fig 24. (X 1-19)
892/00266 Pressure Test ‘T’ Adapters1,1/4 in M BSP x 1,1/4 in F BSP x Test Point Fig 24. (X 1-19)
892/00267 Pressure Test ‘T’ Adapter 1,1/2 in M BSP x 1,1/2 in F BSP x Test Point Fig 24. (X 1-19)
892/00279 Pressure Gauge 0-400 bar (0-6000 lbf/in2) Fig 27. (X 1-20)
892/00346 Pressure Gauge 0-70 bar (0-1000 lbf/in2) Fig 27. (X 1-20)
892/00347 Connector Fig 27. (X 1-20)
993/99512 Spanner 55 mm A/F Fig 28. (X 1-20)
993/99513 Spanner 60 mm A/F Fig 28. (X 1-20)
993/99514 Spanner 65 mm A/F Fig 28. (X 1-20)
993/99515 Spanner 70 mm A/F Fig 28. (X 1-20)
993/99516 Spanner 75 mm A/F Fig 28. (X 1-20)
993/99517 Spanner 85 mm A/F Fig 28. (X 1-20)
993/99518 Spanner 90 mm A/F Fig 28. (X 1-20)
993/99519 Spanner 100 mm A/F Fig 28. (X 1-20)
993/99520 Spanner 110 mm A/F Fig 28. (X 1-20)
993/99521 Spanner 115 mm A/F Fig 28. (X 1-20)
993/99522 Anchor Side Plate (supplied loose unwelded) Fig 20. (X 1-18)
993/99523 Anchor Cross Member (supplied loose unwelded) Fig 20. (X 1-18)
993/99524 Ram Eye End Modification Plate Assembly Fig 20. (X 1-18)
993/99525 Rig Assembly (not including spanners and ram) Fig 20. (X 1-18)
SSP0046 Spanner 80 mm A/F Fig 28. (X 1-20)
SSP0047 Spanner 95 mm A/F Fig 28. (X 1-20)
Socket Box Wrench Fig 29. (X 1-21)
Nut Adapter Fig 30. (X 1-22)
Seal Ring Tool Fig 31. (X 1-23)
Stopper Fig 32. (X 1-24)
Bearing Rig Fig 33. (X 1-25)
Part
Number
Description Tool D e t a il
Reference
