jcb TFT - Main Component Locations; Machine

01 - Machine
09 - Description
12 - Main Component Locations
01 - 15 9813/5250-1 01 - 15
12 - Main Component Locations
Introduction
For: 2TFT, 2THS, 2TST ............. Page 01-15
For: 3.5TST, 3TFT, 3TST ........... Page 01-16
(For: 2TFT, 2THS, 2TST)
Figure 4.
A
D
F
G
E
B
C
A ROPS (Roll-Over Protective Structure)
B Hand rail
C Engine
D Tyres
E Steps
F Head lights
G Skip
