JCM EBA-30 User Manual

1 - 2
CHAPTER 1 Product Name & Product Specifications
EBA product name constitutes two kinds; [MODEL] name and [TYPE] .
As for (1) to (6), refer to the description of the optional items.
[MODEL] EBA - 3 * - SD3 ( EBA - 3 * )
(1) (1)
[TYPE] *** - * * * * - **
(2) (3) (4) (5) (6) (7)
JCM provides optional items for this model. Please consult JCM sales representatives for details.
(1) Type of CPU board
Two types of CPU boards (Flash-ROM or EP-ROM) are available.
0: DC12V Flash-ROM type board for ID-003/MDB interface (Standard)
1: DC12V EP-ROM type board for ID-003/MDB interface
2: DC12V Flash-ROM type board for ID-003/ccTalk/HII Interface (Standard)
3: DC12V EP-ROM type board for ID-003/ccTalk/HII Interface
4: DC12V/DC24V Flash-ROM type board for ID-003/MDB interface (Standard)
5: DC12V/DC24V EP-ROM type board ID-003/MDB interface
(2) The country code corresponding to acceptable banknotes: 3-digit code under ISO3166 shall be
used. Refer to the country codes on page 1-11.
(3) Cash Box type
0: Without box (stackerless model)
4: 400-note capacity (Standard)
6: 600-note capacity (To be developed)
(4) Faceplate
0: Without faceplate (Standard)
1: With faceplate
(5) I/F conversion board
0: Without I/F conversion board (Standard)
1: With Type A I/F conversion board (For serial-to-parallel conversion. To be developed)
(6) Key Switch
0: Without Key Switch (Standard)
1: With Key Switch
2: With Key Switch (for User A)
(7) Interface protocol ID
03: ID-003 JCM serial interface
D3: ID-0D3 MDB interface
E3: ID-0E3 ccTalk interface (Note 1)
F3: ID-0F3 HII interface (Note 2)
**: Others The last two digits of interface ID are assigned.
Example: EBA-30-SD3-CZE-4000-03
EBA-30 model bill acceptor with standard SD3 stacker box, Czech software,
no faceplate, no I/D conversion board, no key switch, ID-003 I/F.
Note 1) "ccTalk" is a serial communication protocol provided by Money Controls.
Note 2) "HII" is a serial communication protocol provided by Mars Electronics International.
1. Product Name (Model Name + Type)

JCM EBA-30 Specifications

General

Brand	JCM
Model	EBA-30
Category	Industrial Equipment
Language	English
