JD-MEDIA PA-112 User Manual

1.󰼿교류󰼿전원󰼿소켓
교류󰼿전원󰼿공급용󰼿소켓이며,󰼿전면의󰼿주전원󰼿스위치가󰼿"OFF"된󰼿상태에서
전원󰼿코드를󰼿끼워󰼿주십시오.
휴즈는󰼿제품󰼿내부의󰼿전원부󰼿PCB상의󰼿FU1󰼿입니다.󰼿
제품의󰼿주󰼿전원󰼿스위치가󰼿"OFF"된󰼿상태에서󰼿제품에󰼿전원󰼿공급을󰼿콘트롤󰼿
하기󰼿위한󰼿단자입니다.
2.󰼿교류전원󰼿원격제어󰼿단자
3. DC POWER TERMINALS
교류󰼿전원이󰼿정전되었을때󰼿직류󰼿24V󰼿배터리로󰼿부터󰼿전원을󰼿공급받는󰼿직류󰼿
전원󰼿입력단자󰼿입니다,
3.󰼿배터리󰼿전원(+24V)󰼿입력단자.
1. AC POWER In-let
This is AC power In-let, Please connect power plug after main power
switch "OFF".
Fuse: Built in the PCB FU1
This is a terminal of AC Power remote control for power supply to
the equipment under AC mains "OFF" .
This is terminals for DC24V battery power supply, When unexpected
AC power failure.
be replaced with same type just like following table, if it
continues to blown out, stop replacing fuse and refer
servicing to qualified person.
IMPORTANT NOTICE : When fuse is blown out, it should
자격이󰼿있는󰼿사람이󰼿휴즈를󰼿교체하십시오.
중요사항󰼿:󰼿휴즈를󰼿교체시에는󰼿반드시󰼿규정된󰼿정격󰼿휴즈를󰼿
2. AC POWER REMOTE
R
EAR PANEL CONTROLS
DC power. Please note the +, - polarity, when connecting DC
24V terminal in case of using emergency power source for
unexpected AC power failure. For the use the cable length
within 4m/5.0mm diameter.
FUSE : Built in the PCB FU3 , FU4.
IMPORTANT NOTICE : Be sure to link per +, - for
1
2
용하십시오.󰼿배터리와󰼿연결시󰼿(-)전원󰼿단자를󰼿연결후󰼿(+)전원󰼿󰼿
단자를󰼿연결󰼿하십시오.󰼿연결시󰼿전원󰼿극성이󰼿잘못󰼿연결되면󰼿제품󰼿
에󰼿결함이󰼿발생될수󰼿있으니󰼿주의󰼿바랍니다.
배터리󰼿연결󰼿케이블은󰼿직경이󰼿5.0mm이상󰼿길이󰼿4m이내로󰼿
사용󰼿하십시오.󰼿
휴즈는󰼿제품󰼿내부의󰼿전원부󰼿PCB󰼿FU3,4입니다.
중요사항󰼿:󰼿DC󰼿POWER󰼿연결시󰼿+측과󰼿-측의󰼿󰼿󰼿󰼿과󰼿󰼿󰼿󰼿단자를󰼿사
1
2
5
24V
AC POWER REMOTE
AC POWER REMOTE
SWITCH
CONTROL SIGNAL
OR
AC POWER
REMOTE
G
How to connect battery.
3
PA - 224D/DP/DPT : T20AL 32V(AFE) X 2PCS
PA - 412D/DP/DPT : T40AL 32V
PA - 424D/DP/DPT : T40AL 32V X 2PCS
PA - 136D/DP/DPT : T30AL 32V
PA - 148D/DP/DPT : T40AL 32V
PA - 112D/DP/DPT : T10AL 250V(65TL)
PA - 124D/DP/DPT : T20AL 32V(AFE)
PA - 212D/DP/DPT : T10AL 250V(65TL) X 2PCS
PA-112(D/DP/DPT)
PA-124(D/DP/DPT)
PA-212(D/DP/DPT)
PA-136(D/DP/DPT)
PA-148(D/DP/DPT)
PA-224(D/DP/DPT)
PA-412(D/DP/DPT)
PA-424(D/DP/DPT)
220󰼿/󰼿230󰼿/󰼿240󰼿VAC120󰼿VAC
T3.15AH󰼿250V(55T)
T3.15AH󰼿250V(55T)
T5AH󰼿250V(55T)
T2AH󰼿250V(55T)
T6.3AH󰼿250V(55T)
T6.3AH󰼿250V(55T)
F6.3AH󰼿250V(55F)
T10AL󰼿250V(65TL)
T12AL󰼿250V(65TL)
F12AL󰼿250V(3AB)
F12AL󰼿250V(3AB)F25AL󰼿250V(3AB)
MODEL
VOLTAGE
4.󰼿GROUND/LIFT󰼿스위치
회로의󰼿접지를󰼿샤시에󰼿접지시키는󰼿스위치󰼿이며,󰼿시스템󰼿구성시에󰼿접지󰼿󰼿
전위차로󰼿발생되는󰼿문제점들을󰼿해결할󰼿수󰼿있습니다.
4. GROUND / LIFT SWITCH
This switch is for grounding between circuit ground and chassis
ground to avoid problems like an electrical potential difference.
This is slot for installation of FD-200 (Fault detector module).
5.󰼿FD-200󰼿SLOT
5. FD-200 SLOT
FAULT󰼿DETECTOR󰼿MODULE󰼿(FD-200)을󰼿장착하기󰼿위한󰼿슬롯입니다.
블랭크󰼿판넬을󰼿제거후󰼿FD-200모듈을󰼿장착하여󰼿사용하십시오.
