Assembly Instructions
10
Step 9
D
F
D
x25
F
x1
Attach the back panel
to the unit.
Use the panel pin guide
when locating the panel
pins. This will hold the
panel pins vertical and
ensure the correct
distance from the edge.
Stand the unit on its
top once this step is
complete.
7225
TAPED SIDE TO
BACK
Step 10
Attach feet to bottom
panel
L
x4
O
x4
Use 4 screws to attach
feet to bottom panel
.
L
5377
O
Use a bradawl to mark
the holes for the feet.
Stand the unit upright
once this step is
complete.
May require 2 people.
O
O
O
O
L
L
L
L
5377
