JD Williams Aspen - Cabinet Frame Assembly Steps 6-7; Step 6: Connect Top Panel to End Panels; Step 7: Connect Bottom Panel to End Panels

5385
Assembly Instructions
9
Step 6
Step 7
Connect the dowels in
the top panel to
the cams in the end panels
.
Turn cams 180 degrees to
lock.
Connect the top panel
to the left and right
end panels.
5385
0314
Locate the wooden dowels
in the end panels
into the inner holes in the
bottom panel .
Use screws to secure.
Connect the bottom
panel to the end panels.
0314
5377
Step 8
Squaring up the unit.
IMPORTANT!
Before securing the back
it is necessary to square
up the unit.
You can do this by
measuring between
XX - XX and YY - YY
ensuring these are the
same (DIAG 1).
If they are not (DIAG 2)
Apply slight pressure as
indicated (DIAG 3) until
they are the same.
Ensure a tape
measure is used
to square unit up.
DIAG 3
DIAG 1
XX
XX
YY
YY
XX
XX
YY
YY
0314
DIAG 2
XX
XX
XX
XX
YY
YY
YY
YY
0314
0314
5377
0314
Overhang
to the floor
Panels sit flush
Overhang
to the floor
Panels sit flush
N
x4
N
N
N
N
N
