ELECTRICAL EQUIPMENT - 12V
B
ATTERY CHARGER
Operation
The battery charger operates based on a signal processor that converts alternating current
(220V or 110V) into a direct current (12V). The operation of the charger is fully automatic, after
selecting the type of battery and load type (Refer to the instructions for use).
BATTERY SWITCH - 12V
Location: Companionway - Starboard
BATTERY SET - 12V
Location: Chart table
1. Common negative
2. Service positive
3. Positive engine
1. Engine: 60A
2. Service: 50A
BATTERY CHARGERS - 12V 25A
Location: Companionway - Starboard and port
VOLTMETER - 12V
Location: Electrical panel
GENERAL FUSE -
12V SYSTEM
