93/148
12V BREAKER
Location: Electrical panel
1. Sockets 12V - Cockpit + Electrical panel
2. Sockets 12V - Forward cabin
3. Sockets 12V - Aft cabin
4. Hifi
5. Amp - TV
6. VHF
7. Available
Mechanism
Circuit breakers are resettable.
Press the tab manually on black back on the road circuit (see photo)
Breaker disarmed Armed breaker
9
        
ELECTRICAL EQUIPMENT
