5
O
PERATING METHOD (동작방법)
It displays on the LCD as follows when power on.
전원이인가되면LCD상에다음과같이표시되어3회점멸합니다.
If no record of previous fault data on the unit, it decrease time
by second and displays automatic checking time selected by
user.
이전에기록되었던폴트상태가없으면사용자가설정한자동체크
시간이표시되며초단위로감소합니다.
(Int.=Interval)
(H=Hour, M=Minute, S=Second)
(Ext.=External)
ex)Incaseofch3fault.
(예:채널3이그라운드폴트인경우다음과같이
표시됩니다.)
If record of previous fault data on the unit, it displays status of
fault and relative channel. (Buzzer will be operated in actual
fault data only)
이전에기록되었던폴트상태가있으면해당채널과상태가표시
됩니다.(실제로체크된경우가아니면부저는동작하지않습니다.)
J S C - 1 3 2 A
L i n e C h e c k e r
1. CHECKING PER CHANNEL AND MEMORY
1.채널별체크및기억방법
1)"CHANNELSELECTOR"버튼을사용하여체크하고자하는채널을
선택합니다.
해당채널의입력값이표시됩니다.
It displays status of each channel which was memorized.
기억되었던각채널의상태가표시됩니다.
It displays status of memorized channel after release of
"CHECK STOP" on the rear panel or after 10 seconds from the
pushing button on the front panel.
전면의각버튼을누른후일정시간(약10초)이경과하거나후면의
"체크정지"입력이들어왔다가해제된이후에는다시이전에기억
되었던각채널의상태가표시됩니다.
It displays on the LCD as below and stop all operatings incase
of "input CHECK STOP" on the rear panel
1) Select the channel by CHANNEL SELECTOR.
It displayes standard level of memorized channel adjustment.
후면의"체크정지"가입력된경우에는다음과같이표시되어점멸
하며,해제시까지모든동작은정지됩니다.
해당채널의릴레이보드가연결되지않았다면"Notconnected!"
가표시되며,"CHECK"버튼을눌러도체크는수행되지않습니다.
It will be displayed "not connected" on the LCD, if relative
relay board is not connected and it will not act on check even
though pushing the "CHECK" button.
해당채널의릴레이보드가연결되어있더라도해당채널의
스위치가"OFF"된상태이면"SwitchOff!"가표시되며,"CHECK"
버튼을눌러도체크는수행되지않습니다.
It will be displayed "SWITCH OFF" on the LCD, if status of
switch is OFF and it will not check even though pushing the
"CHECK" button.
E x t . I n p u t t e d !
M e a s u r e D i s a b l e d
C h 0 1 1 0 0
W A T T
C o n n e c t e dN o t
S w i t c h O f f
!
I n t . R e s t T i m e
H : M : S = 0 1 : 0 0 : 0 0
C h 3
G r o u n d F a u l t !
①
②
③
②
③
①
C h 0 1 1 0 0
W A T T
C h 0 1 1 0 0
W A T T
