Cadence Performance Specifications
Overall Gain (@ 1 kHz)
Lo-Gain 64dB
Hi-Gain 74dB
RIAA Accuracy ± .03 dB, 20 Hz to 20 kHz
Frequency Response - 3 dB @ 0.5 Hz and 180 kHz
Common Mode
Rejection Ratio
130 dB (@ 60 Hz)
Total Harmonic
Distortion
(THD) < .015, 20 Hz to 20 kHz, 5 V output level
Output Noise
(IEC A Weighted)
Lo-Gain < 59 Microvolts
Hi-Gain < 60 Microvolts
Cartridge Loading
Equivalent Resistance
Lo-Gain, Lo-Impedance 250 ohms
Lo-Gain, Hi-Impedance 400 ohms
Hi-Gain, Lo-Impedance 30 ohms
Hi-Gain, Hi-Impedance 50 ohms
Power Requirements ± 12-14 Volts DC, 40 Milliamps
Input/Output Connections
Balanced 1 per channel (XLR)
Unbalanced 1 Pair XLR to RCA adapters included
Dimensions 17.5 in (W) x 5.1 in (D) x 3.15 in (H)
44.5 cm (W) x 13.0 cm (D) x 8.0 cm (H)
Weight 27 lbs (12 kg)
Because Jeff Rowland Design Group is constantly analyzing new
design improvements, we reserve the right to change or modify product
specifications without notice or obligation.
