Installation
4
Back of Base
Front of Base
Step 1 Step 2
Place the base on the ground. Remove all 4 clips
(#6) located on cargo carrier. You will reinstall them
on the cargo carrier in later steps.
Place the lid onto the base at approximately a 30°
angle. Move top lid in an up and down motion until
THREE hinge tabs engage with slots.
On the back of the lid, locate key and turn it to be
parallel with the ground to “unlock” and then remove
the key.
When lid is aligned, all 3 hinge tabs will slide down
into the slots as shown above.
Close up of a hinge tab fully engaged.
3 Tabs
Fully Engaged
Fully Engaged
Insert clip (#6) though center hinge tab hole to secure.
Center Hinge Tab Hole
Front of Carrier
To Next Page
