Connections panels
g
f
e
d
a
c
b
1 2 3 4 5 6 7 8 910
ON
h
i
1 2 3 4 5 6 7 8 910
ON
a
b
c
d
f
e
g
h
a – Remote in
b – Power inlet
c – Main fuseholder
d – DMX out (5-pin XLR)
e – DMX in (5-pin XLR)
f – DMX out (3-pin XLR)
g – DMX in (3-pin XLR)
h – DIP switch
i – Data LED
a – Analog 0 - 10 V in
b – Analog 0- 10 V out
c – Remote in
d – Power LED
e – Data LED
f – DIP switch
g – DMX in (3-pin XLR)
h – DMX out (3-pin XLR)
AF-1 Fan
AF-2 Fan
