GENERAL INTRODUCTION:
The model 765 digital indicating panel thermometer is a high performance industrial
grade readout for types K, J, T, E thermocouple sensors and 3-wire RTD (PT-l 00). The
thermocouple gain, linearization, and cold junction are automatically compensated by
internal electronic circuits.
The temperature scale can be easily changed from
to ℉and vice versa by an
internal jumper without re-calibration.
An accurate I mV per display count analog output is provided to interface the
instrument with a recorder, printer, etc.
For rapid changing display, the ''HOLD'' function may be used to freeze the display.
INITIAL INSPECTION:
Carefully unpack the instrument. Inspect damage in shipment. If any damage is found,
notify your JENCO distributor immediately. All packing material should be saved until
satisfactory operation is confirmed.
