(c) When the car has been parked for some time or if the carburetter float
chambers have been dismantled for cleaning, fuel will have to be pumped
to the carburetter before the engine can be started. In these circumstances
operate the fuel pump hand priming lever.
(Fig.
2).
Fig.
3.
The full flow oil filter should
only be dismantled when the
filter element is to be renewed.
(a) Centre fixing bolt.
(b)
Filter casing drain plug.
(c) Filter element.
(d) Oil sump Drain plug.
The change speed arrangement being conventional,
we do not propose to describe the method of engaging
and changing gear, but we give here a plan showing the
gear lever positions.
(Fig.
4.)
Fig.
'4.
Overdrive.
The overdrive
is
an optional extra.
To engage overdrive, which can only be
operated from fourth speed position, all that
is
required
is
to pull switch on facia
marked
overdrive.
No movement of the clutch or alteration of accelerator pedal
is
necessary. Reverse process to return to fourth speed position.
PAGE
SIX
