19
CM9MIR
Rear RCA A/V Input
Rear Camera Operation - (Optional)
Connect an optional audio/video source into the RCA (rear) input.
Adjust volume on the external audio source as needed (if connected to the
headphone output of the device).
Connect an optional rear camera to the Camera Input (Black RCA connector).
Refer to the camera's wiring diagram for installation details.
The unit will automatically select camera mode when connected to the reverse
lamp circuitry.
A/V Input
Rear Camera Input
Auto Selection
