Jensen MCD5090 - Wiring; View A; View A-A Wire Insertion View; Pin No. Wire Color Function

MCD5090
4
WIRING
+12V DC SWITCHED (ACC)
FRONT RIGHT SPEAKER (+)
FRONT RIGHT SPEAKER (-)
FRONT LEFT SPEAKER (+)
FRONT LEFT SPEAKER (-)
DIMMER
NO CONNECTION
AUTO ANTENNA OUTPUT
REAR RIGHT SPEAKER (-)
REAR RIGHT SPEAKER (+)
REAR LEFT SPEAKER (-)
REAR LEFT SPEAKER (+)
GROUND
+12V DC BATTERY
RED
GRAY
GRAY/BLACK
WHITE
WHITE/BLACK
ORANGE
EMPTY
BLUE
PURPLE/BLACK
PURPLE
GREEN/BLACK
GREEN
BLACK
YELLOW
PIN NO. WIRE COLOR FUNCTION
10 AMP FUSE
7
14
1
8
+12V DC
Battery
+12V DC
SWITCHED
GROUND
DIMMER
