Operation / Operación / Fonctionnement
Power
Volume
Mode
Band
Pause
Clock/Info
Tuning
Wiring
Once the remote has been mounted, route the cable from the remote and connect the cable to the
radio. Note the connector polarity on the extension cable. The 18 foot extension cable may be
used to connect the remote to the radio. Up to two additional extension cables (MWREXT) may be
purchased and used to extend the reach of the remote up to 54 feet. Important: When connecting
the cables, be sure to route the extension cable away from sharp objects, corners, and places
where it might get pinched, as this could affect performance and cause damage to the unit. Up to
two more remote controls can be added with a "Y" cable adapter (MWRYCBLS).
POWER
BAND
MODE
MWR75
INFO
VOL
VOL
MUTE
