EN
3. SPECIFICATIONS
Machine SHDC 8320 HDC 8230N HDC 8200
Voltage (see machine label) 230 V / 50 Hz
110 V / 60 Hz
230 V / 50 Hz
110 V / 60 Hz
230 V / 50 Hz
No load speed 1.700 rpm 2.200 rpm 3.700 rpm
Power input 1.800 W 1.700 W 1.700 W
Max. saw blade diameter 320 mm | 12 5/8” 230 mm | 9” 203 mm | 8”
Bevel capability 0° 0°~45° 0°~45°
Arbor hole diameter 25,4 mm | 1“ 25,4 mm | 1“ 25,4 mm | 1“
Max. cutting depth 120 mm | 4.72”
(on guide rail)
90°: 82 mm | 3.22”
45°: 56 mm | 2.20”
90°: 67 mm | 2.63”
45°: 42 mm | 1.65”
Net weight 8,4 kg | 18,5 lbs 7,1 kg | 15,7 lbs 6,3 kg | 13,9 lbs
Noise level ISO1999 DIN45635 99,0 dB (A) 88,5 dB (A) 88,5 dB (A)
Sound pressure level 110,0 db(A) 99,5 db(A) 99,5 db(A)
Hand-arm vibration 1,4 m/s
2
1,0 m/s
2
1,0 m/s
2
Information referred to 2.2 of Annex 1 of the E. G. Directive on vibrations)
4. USER INSTRUCTIONS
Notes for the customer
The instruction manual includes important
instructions as to how to operate the machine
safely, correctly and economically. Observing
these instructions helps to avoid risks, repair costs
and downtimes and to increase the reliability and
lifetime of the machine.
The instruction manual must be read and used
by each person who works with the electrical
equipment. This applies in particular to the
“Safety Instructions” chapter. It is too late to read
the manual and safety instructions when work is
actually being carried out at the machine.
Always keep one copy of this manual next to the
machine so that it is at hand ready to be consulted!
In case of any doubt or questions, always contact
the machine manufacturer.
In addition to the instruction manual, the accident
prevention regulations which apply in the country
of use and the user location must be adhered to. In
addition, the recognised technical rules regarding
accident prevention must be observed.
Liability and warranty
All the information contained in this instruction
manual has been drawn up to the best of our
knowledge and belief, taking our experience to date
into consideration.
The original version of this instruction manual was
drawn up in the German language and was checked
by us for accuracy of content. The translation into
the respective national/contractual language was
carried out by a recognised translation agency.
This instruction manual has been put together with
the greatest of care. However, if you should discover
any incomplete items or mistakes, please inform us
in writing. Your suggestions for improvement will
help us to create a user-friendly manual.
Subsequent Orders and Copyright
Further copies of this instruction manual can be
ordered from the address below. We ask for your
understanding that further copies are subject to
charge.
Jepson Power GmbH
Ernst-Abbe-Straße 5
D-52249 Eschweiler
Phone: +49 (0)2403 – 6455-0
Fax: +49 (0)2403 – 6455-15
Mail: info@jepson.de
All rights are expressly reserved. Duplication or
transfer on to third parties in any form whatsoever
is not allowed without our prior written permission.
GENERAL
5
