Section II: Operation
Page 22
5-376-000102
REV. 1 - 07/10
3. To release the ratchet, simply pull
on the locking bar, disengaging
the teeth and raise the handle to
the “free spool” position.
INSTALLING THE TIE DOWN STRAP
1. With the vehicle lifted just barely
off the ground, insert the end of
the strap through the sewn loop
on the other end of the strap to
form a loop. Put the loop over
the tire as shown with the strap
resting on the tire at the ten
o’clock and two o’clock positions.
The choker strap should be
across the center of the tire.
2. Place the rear hook of the strap
assembly into a hole on the back
side of the grid arm. Try to use
the hole that is closest to the tire.
