12
WHILE PRESSING DOWN THE EXTENSION ON
ELECTRICAL CONNECTOR B, SLIDE CONNECTOR
A INTO CONNECTOR B UNTIL THERE IS A "CLICK,"
SIGNIFYING THAT THE CONNECTORS ARE
SECURELY ATTACHED.
ELECTRICAL CONNECTOR B
ELECTRICAL CONNECTOR A
