Jetson JUPITER Guide

12
1.2 Handlebar Assembly
1. USING THE SCREWDRIVER TIP OF THE 2BIT TOOL, UNSCREW THE PREATTACHED BOLT AND NUT FROM THE BASE OF
THE HANDLEBAR.
2. SLIDE THE HANDLEBAR ONTO THE SCOOTER STEM.
3. PUSH DOWN AND ADJUST UNTIL THE HOLES IN THE HANDLEBAR BASE ARE ALIGNED WITH THE HOLES IN THE STEM.
4. FROM THE RIGHT SIDE WHEN STANDING ON THE SCOOTER, INSERT THE BOLT THROUGH ALL FOUR HOLES.
TIGHTEN WITH THE SCREWDRIVER.
IMPORTANT: PLACE THE BOLT ON THE RIGHT SIDE WHEN FACING THE FRONT OF THE SCOOTER FROM RIDING POSITION.
PLEASE MAKE SURE THAT THE BOLT AND NUT ARE SECURED AND TIGHTENED PRIOR TO RIDING.
NUTBOLT
HANDLEBAR HOLES

Jetson JUPITER Specifications

General

Motor Power	350W
Battery Capacity	36V 7.8Ah
Charging Time	4-5 hours
Foldable	Yes
Max Speed	25 km/h
Range	30 km
Tire Size	8.5 inch
Brake Type	Disc brake
