Jetson Light Rider User Manual

20
1.4 Installing the Handlebar
CAP BOLT
WEDGE NUT
HEAD TUBE
YOU WILL NEED THE 13MM WRENCH.
1. LOOSEN THE CAP BOLT ON THE TOP OF THE HANDLEBAR BY TURNING IT COUNTERCLOCKWISE FOR 12 ROTATIONS
WITH THE 13MM WRENCH.
2. POSITION THE HANDLEBAR ABOVE THE HEAD TUBE WITH THE HANDLEBAR POST IN LINE WITH THE STEM AND THE BELL
ON THE RIGHT SIDE OF THE BIKE.
3. SQUEEZING AND MANIPULATING THE WEDGE NUT SO THAT IT FITS INTO THE HEAD TUBE, SLIDE THE HANDLEBAR POST
ALL THE WAY INTO THE HEAD TUBE.
NOTE: IF THE WEDGE NUT DOES NOT FIT INSIDE THE HOLE OF THE HEAD TUBE, YOU MAY NEED TO LOOSEN THE CAP
BOLT FURTHER.
13MM WRENCH
BELL
HANDLEBAR
