JETStream JMC-1105 - Parts List

- 7 -
NO. DESCRIPTION Q'TY
1 Main frame 1
2 Front stand tube 1
3 Rear stand tube 1
4 Bolt M8 x 60 4
5 Arc washer 8 x 20 8
6 Domed nut M8 4
7 Washer 8 x 17 x 1.2 3
8 Saddle 1
9 Seat post 1
10 Hand pulse sensor 2
10A Hand pulse wire 1
11 Nut M8 4
12 Handlebar post 1
13 Tension control cable up 1
14 Tension control cable low 1
14A Metal clip 1
15 Bushing 1
16 Tension control 1
17 Foam grip 2
18 Adjustment knob 1
19 Computer cable up 1
20 Monitor 1
20A Screw M5 x 14 2
21 Computer cable low 1
22L/R Pedal L/R 1/1
23 Cap for handlebar 2
24 T-knob 1
25 Handlebar 1
26 Front stand cap 2
27 Rear stand cap 2
28 Bolt M8 x 16 4
29 Washer 8 x 17 x 2 1
30L/R
31L/R
Chain cover L/R 1/1
Decoration cover L/R 1/1
PARTS LIST
GB
JMC1105-060622GB-DA01
