JETStream JMC-4900 - Parts List with Quantities

- 5 -
PARTS LIST
KEY. DESCRIPTION Q'TY
1 MAIN FRAME 1
2 SEAT SUPPORT FRAME 1
3 REAR STABILIZER 1
4 SEAT BENDING TUBE 1
5 SEAT- BACK TUBE 1
6 CHAIN COVER(L/R) 1
7 BACK-SEAT 1
8 SEAT 1
9 COMPUTER 1
10R PEDAL(R) 1
10L PEDAL(L) 1
11A PLUG OF CABLE(UP) 1
12 SEAT ADJUSTMENT KNOB 1
13 HANDLEBAR 1
14 COMPUTER SUPPORT TUBE 1
11B PLUG OF CABLE (LOW) 1
15 COMPUTER CABLE (UP) 1
16 COMPUTER CABLE(LOW) 1
17 BOLT 3
18 WASHER 7
19 CRANK HOLE COVER 2
20 SENSOR CABLE 1
21 STUD 1
22 FRONT CAP 2
23 REAR CAP 2
24 DOMED NUT 2
25 BOLT 2
26 BOLT 4
27 WASHER 4
28 BOLT 4
29 WASHER 6
30 BOLT 2
31R CRANK(R) 1
31L CRANK(L) 1
32 BOLT 2
33 NUT 2
34 BOLT 2
35 END CAP 1
36 HANDLE GRIP 2
37 END CAP 2
38 END CAP 1
39 TENSION CONTROL 1
40 PULSE PIECE 2
41 SCREW 4
