JFE Advantech RINKO FT - Page 41

4. Commands:
HC to RINKO F
T
RINKO FT to H
C
Description
Request Response
Outline Detail
do do,HEX
Send DO,
enter sleep mode.
Turn ON the analog power (if it is in sleep mode), send the DO physical data [μ
mol/L], and enter sleep mode. If the RINKO FT analog power is OFF when receiving
the command, it takes 5 seconds for the DO value to stabilize. For that reason, DO
NOT USE this command during the sleep mode because the RINKO FT again enters
sleep mode immediately after sending unstable/unreliable data.
tdo tdo,HEX,HEX
Send T and DO,
enter sleep mode.
Turn ON the analog power (if it is in sleep mode), send the temperature and DO
physical data [°C and μmol/L], and enter sleep mode. If the RINKO FT analog power
is OFF when receiving the command, it takes 5 seconds for the DO value to stabilize.
For that reason, DO NOT USE this command during the sleep mode because the
RINKO FT again enters sleep mode immediately after sending unstable/unreliable
data. The left and right HEXs represent temperature and DO, respectively.
sdo sdo,HEX Send DO.
Turn ON the analog power (if it is in sleep mode) and send the DO physical data [μ
mol/L]. If the RINKO FT analog power is OFF when receiving the command, it takes
5 seconds for the DO value to stabilize.
stdo stdo,HEX,HEX Send T and DO.
Turn ON the analog power (if it is in sleep mode) and send the temperature and DO
physical data [°C and μmol/L]. If the RINKO FT analog power is OFF when
receiving the command, it takes 5 seconds for the DO value to stabilize. The left and
right HEXs represent temperature and DO, respectively.
tdon
tdon,HEX,HEX,H
EX
Send AD values of T and DO
and LED time,
enter sleep mode.
Turn ON the analog power (if it is in sleep mode), and send the temperature and DO
AD values and LED accumulated time, and enter sleep mode. If the RINKO FT
analog power is OFF when receiving the command, it takes 5 seconds for the DO
value to stabilize. For that reason, DO NOT USE this command during the sleep
mode because the RINKO FT again enters sleep mode immediately after sending
unstable/unreliable data. The first HEX represents the temperature, the second the
DO, and the third the LED accumulated time.
tdona
tdona,HEX,HEX,
HEX,HEX,HEX,
HEX,HEX
Send all parameters as AD
values and LED time,
enter sleep mode.
Turn ON the analog power (if it is in sleep mode), send temperature and DO AD
values, phases of the blue and red lights (AD values), amplitudes of the blue and red
lights (AD values), and LED accumulated time, and then enter sleep mode. If the
RINKO FT analog power is OFF when receiving the command, it takes 5 seconds for
the DO value to stabilize. For that reason, DO NOT USE this command during the
sleep mode because the RINKO FT again enters sleep mode immediately after
sending unstable/unreliable data. The first HEX represents the temperature, the
second the DO, the third the blue phase, the fourth the red phase, the fifths the blue
amplitude, the sixth the red amplitude, and the seventh the LED accumulated time.
stdon
stdon,HEX,HEX,
HEX
Send AD values of T and DO
and LED time.
Turn ON the analog power (if it is in sleep mode) and send the temperature and DO
AD values and LED accumulated time. If the RINKO FT analog power is OFF when
receiving the command, it takes 5 seconds for the DO value to stabilize. The first
HEX represents the temperature, the second the DO, and the third the LED
accumulated time.
stdona
stdona,HEX,HEX,
HEX,HEX,HEX,
HEX,HEX
Send all parameters as AD
values and LED time.
Turn ON the analog power (if it is in sleep mode) and send temperature and DO AD
values, phases of the blue and red lights (AD values), amplitudes of the blue and red
lights (AD values), and LED accumulated time. If the RINKO FT analog power is
OFF when receiving the command, it takes 5 seconds for the DO value to stabilize.
The first HEX represents the temperature, the second the DO, the third the blue
phase, the fourth the red phase, the fifths the blue amplitude, the sixth the red
amplitude, and the seventh the LED accumulated time.
qs
qs,OK Enter sleep mode.
Enter sleep mode after returning a response. When turning off the power of the
RINKO FT, do so after the RINKO FT is in sleep mode.
*serialnumber *serialnumber=S Display serial number
The serial number of the RINKO FT. “S” is an ASCII string [0-9a-zA-Z]. The length
of the string is 10 at maximum.
dc
(1)dc,OK
(2)Coefficients
Display calibration
coefficients.
(1) First, it gives a response to the command (Response =dc,OK).
(2) Next, returns the calibration Coefficients .
Refer to Chapter 5 for Calibration coefficients.
wu wu,State Wakeup.
Turn ON the analog power (if it is in sleep mode), and send current State of RINKO
FT. Refer to Chapter 7 for State . See also Chapters 3-a and 8 for Error Code 0003.
querys querys,State Display current state. Send the current State of RINKO FT. Refer to Chapter 7 for State .
fwver fwver=S Display firmware version.
Send the firmware version of RINKO FT. “S” is a string, and its format is
“Ver.X.XX”.
- error=Error Code Error response Send the Error Code . Refer to Chapter 8 for Error Code.
Note 1: RINKO FT returns
E
rror Code 0003 to ANY FIRST COMMAND durin
g
the slee
p
mode. RETRY Re
q
ues
t
.
Note 2: Retr
y
Re
q
ues
t
if there is somethin
g
stran
g
e
,
such as no res
p
onse
,
error res
p
onse
,
or unmatched Checksum .
[Appendix 1] 2 /4
