JingYan TLL90S - Page 7

2022 Aug 15
6
Sound notification on.
Blank as off
Show this logo as relative value is showing. When the
Zero button is pressed, the unit reset current angle to
zero.
Direction of tilt icons, show the tilt angle direction
Dual-Axis Mode. Both the X and Y axis angle will be
showed. Dual axis mode measures inclination up to
±40 degree for each axis before it automatically
switch to single axis mode.
Single Axis Mode. Measure slope up to ±90 degree.
The triangle icon indicates the direction of tilt with
respect to the bottom right corner of the unit.
