2 | JL Audio - C2-400x Owner’s Manual
A
F
B
G
E
C
D
Due to ongoing product development, all specifications are subject to change without notice.
Woofer Physical Dimensions
Frame Outer Diameter (A) 4.02 in. / 102.0 mm
Grille Tray Outer Diameter (B) 5.20 in. / 132.2 mm
Magnet Outer Diameter (C) 2.36 in. / 60.0 mm w/o cover
Frontal Tweeter Protrusion (D) 0.56 in. / 14.3 mm
Frontal Grille Protrusion (E) 0.66 in / 16.7 mm
Mounting Hole Diameter (F) 3.81 in. / 96.8 mm
Mounting Depth (G) 1.81 in. / 46.0 mm w/o cover
