Due to ongoing product development, all specifications are subject to change without notice.
Woofer Physical Dimensions
Frame Outer Diameter (A) 6.50 in. / 165.0 mm
Grille Tray Outer Diameter (B) 6.84 in. / 173.7 mm
Magnet Outer Diameter (C) 3.15 in. / 80.0 mm w/o cover
Frontal Tweeter Protrusion (D) 0.45 in. / 11.6 mm
Frontal Grille Protrusion (E) 0.85 in. / 21.6 mm
Mounting Hole Diameter (F) 5.56 in. / 141.3 mm
Mounting Depth (G) 2.44 in. / 61.9 mm w/o cover
