4 | JL Audio - C2-650x Owner’s Manual
5
Connectthespeakerwires,observingcorrect
polarity,andinstallthespeakerandgrilleassembly
asshowninDiagramB(below).Hand-tightenthe
screwsevenlytoavoidbendingthespeakerframe!
TheincludedJLAudiologonamebadgesshould
beaffixedtothecircularindentedareainthelower
partofeachgrilleassembly.Ifthegrilleassemblyis
notused,theJLAudiologobadgescanbeaffixed
elsewhereascreativeadditionstoyourinstallation.
Diagram B:
Custom Location Woofer Installation
Diagram A:
Factory Location Woofer Installation
WARNING
!!
Hand-tighten the screws evenly in a criss-cross
pattern to avoid bending the speaker frame or
stripping the mounting clips.
