4 | JL Audio - C5-650x Owner’s Manual
Amplifier
Output
Red Black
GETTING STARTED
•Turnofftheaudiosystem.Itisalso
advisabletodisconnectthenegative(–)
terminalofyourvehicle’sbatterywhenever
performinginstallationwork.
•Beforecutting,drillingorinsertinganyscrew,
checkclearancesonbothsidesoftheplanned
mountingsurface.Alsocheckforanypotential
obstacles,suchaswindowtracksandmotors,
wiringharnesses,etc.Checkbothsidesofthe
vehicle,manyvehiclesarenotsymmetrical!
•Alwayswearprotectiveeyewear.
CROSSOVER NETWORK INSTALLATION
ThecrossovernetworkssuppliedwithyourC5
Systemshouldbeinstalledinadrylocationinside
yourvehicle.DONOTINSTALLTHEMINSIDEOF
ADOOR!Doorsoftengetwetontheinside,which
candamageyourcrossovernetworksandcould
potentiallydamageyourentiresoundsystem.The
crossoverscanbescrewedintoasolidsurfaceviatwo
holeslocatedundertheprotectivecoverofthecase.
Toaccesstheseholes,simplysqueezethesidesofthe
coverwhilegentlypullingthecoverawayfromthe
base.Makesurethatyourmountinglocationwillnot
causedamagetowiring,fuellines,brakelinesorany
othervitalcomponentofyourvehicle.Onceyouhave
screwedthecaseinandmadeyourconnections,snap
theprotectivecoverbackintoplace.

WARNING
!!
It is absolutely vital that your coaxial system is
connected as shown in this manual. Failure to
connect the system as shown may result in damage to
your speakers which is NOT covered under warranty.
Do not substitute different crossover networks into
your C5 System. Do not use crossover networks
intended for different C5 models.
TWEETER PROTECTION
TheC5crossovernetworksareequippedwith
anadvancedelectronictweeterprotectioncircuit
designedtominimizethepossibilityoftweeter
failure.Thiselectronicdevicemonitorscurrentgoing
tothetweeterandwilldisconnectthetweeterfrom
thesignalwhenitsensesoverload.Shouldthisoccur
whilelisteningtotheaudiosystem,simplyreducethe
volumeforafewsecondsandtheprotectioncircuit
willresetitselfautomatically.
CROSSOVER NETWORK ADJUSTMENT
Thecrossovernetworkshavebeendesignedto
allowtonaladjustmentstotheuppermidrange
responseandtweeterlevel.Theseadjustmentsmake
itpossibletofine-tuneyoursystemtosuityour
listeningpreferencesandtocompensateforvarious
speakermountingapplications.
