6
STEP 3:
Tighten the Pedal (11L/R) to the Pedal Support (6 L/R) with Hexagon Bolt(44) and Nylon Nut
(45).
STEP 4:
Insert the Handlebar (7L/R) to the Swing bar (4 L/R) and tighten with Knob (17), then cover the
nut with Cap (71). You could adjust the height of the Handlebar with different holes.
