Warning: To avid over heating, do not cover the heater.
A. STRUCTURE
B. ASSEMBLY
Place the legs at the bottom of heater in the first and last fins and screw them on. Shown as
following figure 1.
ASSEMBLY WITH STANDS
• Before fixing heater on a wall, be sure that once unit installed it must be kept at a minimum
distance (shown in figure 2) from any objects (side wall, floor, furniture, ect.).
WALL MOUNTING
• Then make 2 holes H1, H2 (diameter: 10mm; depth:60mm) in the wall, the location dimensions
of the holes are vary depending on the model of heater that you have bought. The dimensions
are as follows:
