AVE HAND DRYER
Pag. 4
2. INSTALLATION AND ASSEMBLY
UnscrewthetwoscrewsatpointsAandBontheleandrightoftheinlet/outlet
airoutletasshowninthefollowinggure:

A C B
Toremovethefrontcover,placetheunitinfrontofyouandpullittowardsyouby
exerngslightpressureonthesidesasshowninthefollowinggure:

1.Forthishanddryer,thereare2 installaonoponsforthepowersourceare
possible:
a. DIRECT CONNECTION TOTHE WALL POWER CABLE. In this case,the cable
mustbeinsertedthroughtheD-portandconnectedtothepanelconnecon.
b. When the power supply is faraway from the unit, use a exible cable to
connectthepowersupplytotheunit.forthehanddryer,passitthroughhole
Cingure1andsecureitinplacetothedevice’sjunconbox.
Note:
Thesizeofthecablemustbe2x1.5mm².
Useacablethatcomplieswithnaonalstandards.(UsetheHO5RN-Fcable).
