AVE HAND DRYER
EN
Pag. 5
Mark4pointsonthewallanddrillØ8mmholes,placetheplugsandthenxit
inplacetheunitusingthescrewssuppliedasshowningure3.

D
IMPORTANT:
Amul-poledisconnectorwithacontactgapof3mmmustbeincorporatedinto
theinstallaon.
Theequipmentmustbeinstalledataminimumdistanceof0.6mfromdistance
fromawaterpoint(sink,etc.).
Replacethehousingcoverinthedireconofthearrowsandscrewon.
TightenscrewsAandBingure1rmly.
3. MOTOR MAINTENANCE
ThishandsdryerhasaUniversaltypemotorwhichusescarbonbrushestowork.
Thesecomponentssuerwearandmightbereplacedonesconsumed,thusthe
motorwillcan’tworkwithoutthem.
PleasecontactyourdistributortogetRA4004spareparts.
