- Page 12 -
1.3 MACHINE DIMENSIONS - System I
MACHINE DIMENSIONS - System II and III
547
Figure 2
1.4 STANDARD ACCESSORIES
87111 - Mount /Demount Tool (Fig.3)
294
Figure 3
Inflation Guage is mounted on the Inflation Tank Col-
umn. (Not shown)
Air Filter and Air Lubricator, (Fig.4)
539
Figure 4
Incoming Air Pressure Gauge
Located on the air filter and the air lubricator
Lubrication Bottle
Lubrication Applicator
Replacement Mount/Demount Head Inserts (4)
For Reference Only
For Current Info See Equiserv.com
